Name
-
Name of the connection check
Comment
-
Comment for the event
Enabled
-
Enable or disable this event
Log
-
Each event can be logged to a file. The checkbox enables/disables logging of the event.
Event types
On connect fail
-
Raised if connection to host failed.
On data fail
-
Raised if data read failed.
Connect time
-
Raised if connect time is greater/less than the value.
Data time
-
Raised if data time (complette data read) is greater/less than the value.
Data length
-
Raised if readed data length is greater/less than the value.
Data contatins
-
Raised if readed text data contains the string.
Actions
Number of events
-
The action is raised if event counter reaches the number. Event counter is cleared after the action is raised.
Number of events - continuous
-
The action is raised if event counter reaches the number. Event counter is cleared when event is not raised or after the action is raised.
Events during time
-
The action is raised if the events occurs in the time interval. Event interval is cleared after the action is raised.
Events during time - continuous
-
The action is raised if the events occurs each time in the time interval. Event interval is cleared when event is not raised or after the action is raised.
Action
-
Any OS command (.exe, .bat, .vbs ...)
Parameters
-
Command line for the action.
